Close to a window, on an outside wall, or next to a door leading to the outside.The Infinity Control and Room Sensors should NOT be mounted: On a section of wall without pipes or ductwork.Close to or in a frequently used room, preferably on an inside partitioning wall.Approximately 5–ft (1.5 m) from the floor.The Infinity Control and Room Sensors should be mounted: It should be located where it is easily accessible and visible to the adult homeowner or end-user.įor accurate temperature measurement, the following guidelines should be followed: The Infinity Control User Interface is the command center for the Infinity System. Infinity Control Location and Wiring Considerationsįailure to follow this warning could result in personal injury or death.ĭisconnect power before routing control wiring.Īll wiring must comply with national, local, and state codes.
File claim with shipping company prior to installation if shipment is damaged or incomplete.
Setup, commission, and operating system according to this instruction to assure a smooth and trouble-free startup. Wire complete system according to this instruction. #Carrier infinity flashing yellow light compressor install
Install indoor unit, outdoor unit, and accessories according to their instructions. Install Infinity Control according to this instruction. The special screen prompts and start-up capabilities are provided in the Infinity System to simplify and automate the initial commissioning of the system. It is the guide to connecting the system components andĬommissioning the system once all physical components are installed. Setup, commissioning, operation, and troubleshooting of the Infinity System are covered only in this installation instruction. Physical installation instructions for the indoor and outdoor equipment and accessories are provided with each unit. This instruction covers the installation of the Infinity Control only. Also, the Infinity Network Interface Module (P/N SYSTXCCNIM01) allows the connection of a Carrier HRV or ERV without the need for a separate wall control.Īll system components are controlled through the wall-mounted Infinity Control, which replaces the conventional thermostat and provides the homeowner with a single wall control for all features of the system. When using conventional outdoor units, the Infinity furnace or fan coil provides the 24-volt signals needed to control them. Either an Infinity (communicating), or a standard 24VAC controlled outdoor unit may be used. They support controlled ventilation, humidification, dehumidification, and air quality control. The result is a new level of comfort, versatility, and simplicity.Īll Infinity furnaces or fan coils are variable–speed and multi-stage for maximum flexibility, efficiency, and comfort. Commands, operating conditions, and other data are passed continually between components over the ABCD bus. The Infinity System consists of several intelligent communicating components which include the Infinity Control (or User Interface), variable speed furnace or FE fan coil, 2–stage AC or HP and Infinity Packaged Products, which continually communicate with each other via a four-wire connection called the ABCD bus. NOTE is used to highlight suggestions that will result in enhanced installation, reliability, or operation. CAUTION is used to identify unsafe practices, which may result in minor personal injury or product and property damage. WARNING signifies hazards, which could result in personal injury or death. DANGER identifies the most serious hazards, which will result in severe personal injury or death. These words are used with the safety–alert symbol. Understand the signal words DANGER, WARNING, andCAUTION. When you see this symbol on the unit and in instructions or manuals, be alert to the potential for personal injury. #Carrier infinity flashing yellow light compressor code
In Canada, refer to the current editions of the Canadian Electrical Code CSA C22.1.
Consult local building codes and the current edition of the National Electrical Code (NEC) NFPA 70. Read these instructions thoroughly and follow all warnings and cautions included in literature and attached to the unit. Wear safety glasses, protective clothing, and work gloves. Refer to the individual instructions packaged with the kits or accessories when installing.įollow all safety codes. The qualified installer or agency must use factory–authorized kits or accessories when modifying this product. Consult a qualified installer, service agency or your distributor or branch for information or assistance. Improper installation, adjustment, alteration, service, maintenance, or use can cause explosion, fire, electrical shock, or other conditions which may cause death, personal injury or property damage.
